| Brand Name: | HAGOIN |
| Model Number: | RSIC-1 |
| MOQ: | 1000 |
| Price: | $0.28-0.60 |
| Payment Terms: | T/T |
| Supply Ability: | 1000 pieces per day |
Hagoin RSIC-1 Resilient Rubber Acoustic Mount Clips-Vibration-Resistant Building Clips 5 Year Warranty Enhanced Low Frequency
A Resilient Sound Isolation Clip (RSIC-1) creates a high STC (Sound Transmission Classification) rating for your wall or ceiling assembly and offers an economical method to “float” your walls or ceilings. These isolation clips are used for vibration control of structure-borne noise and help build assemblies that will more effectively block airborne noise transmission. For higher rated sound blocking applications with improved STC ratings, use isolation clips in combination with our AudioSeal® Sound Barrier or Green Glue Damping Compound.
Resilient Isolation Clips are made with a natural blend neoprene grommet pad and threaded shaft, which is attached to a center bushing made of electroplated zinc mild steel. The center bushing is approximately 20 mm long, with a 10 mm shaft section and 21.5 mm end clip. The natural neoprene isolator is 1 1/2″ x 1/2″.
The RSIC-1 model is designed for use with any wood, steel or concrete application where noise control is required. This includes, wood framed, steel framed, CMU or concrete wall or ceiling systems. The RSIC-1 assembly decouples the gypsum board from the underlying structure to provide enhanced acoustical performance. With an acoustical design load rating of 36 lbs. per isolator, the clip can support up to two layers of 5/8″ gypsum board when spaced no more than 24″ x 48″ O.C. The RSIC-1 clip fastens directly to the framing or structure to prevent sound and vibrations from entering the adjacent space. This improves the STC and IIC ratings of construction assemblies.
Sound isolation clips are designed to allow a decoupling separation between the walls and ceiling from the underlying framing studs and joists. When utilizing sound isolation clips for drywall installation, the drywall furring channels (AKA “hat” channels) are attached to the clips and the clips are then fastened to the studs or joists, following the supplied instructions. Once installed, the drywall (or other wall material) is isolated from the framing. This significantly lowers the ability for sound, especially low frequency sound, from transmitting into the room where they're installed.
Detailed Images
Production Process
Packaging & Shipping
| Packing Details | Plastic bag packing, put into nylon or carton, outside is stretch film, Stick the shipping marks, We also can according to the customer's requirement. |
| Transportation | Transportation item will be by express, vessel, air. |
Our Services
We have more than 12 years trading experience and complete sale service, hope we can get nice cooperation with each other, our website: www.hagoinchina.com , welcome you to visit us and hope can cooperate with you. Do believe that we can offer competitive price & quality With best service.
FAQ
1. Q: How many days for mould open and sample produce?
A: Open mould need 3-5 days, sample produce need 3days.
2. Q: What is the mould and sample charge?
A Mould charge is suffered by customer, we will supply best price for mould charge. Sample charge based on the quantity, little sample is free. Expres charge paid by customer
3. Q: OEM/ODM is accept or not?
A: OEM/ODM is welcomed, we can also print the logo according to your requirement. PS: Only for non-infringing OEM/ODM is enabled.
4. Q: Delivery Time
A: Usually after the shipment, within 15days goods will be finished shipment.
5. Q: Quality Control and After Sales Service
A: During production we have strict inspection system for the production, if there is problem happens, we will try our best help solving the problem, such like bank, transportation, if there is quality problem confirmed, we also will undertake responsibility and suffer.
6. Q: Is price can be discount?
A: Based on the quantity we will make the best quoation, so discount will be based on the quantity.
