| Brand Name: | HAGOIN |
| Model Number: | AH-3 |
| MOQ: | 1000 |
| Payment Terms: | T/T |
| Supply Ability: | 1000 pieces per day |
| Model | Load (Kg) | Spring Coefficient (N/mm) | Spring Color | Size (mm) | |||||
|---|---|---|---|---|---|---|---|---|---|
| Height | A | B | C | E | D | ||||
| AH-320 | 20 | 8 | Black | 130 | 59 | 80 | 45 | 12 | 12 |
| AH-350 | 50 | 20 | Silver White | 130 | 59 | 80 | 45 | 12 | 12 |
| AH-380 | 80 | 32 | Yellow | 130 | 59 | 80 | 45 | 12 | 12 |
| AH-3120 | 120 | 48 | Dark Blue | 170 | 73 | 100 | 50 | 12 | 14 |
| AH-3170 | 170 | 68 | Gray | 170 | 73 | 100 | 50 | 12 | 14 |
| AH-3200 | 200 | 80 | Blue | 200 | 88 | 120 | 75 | 16 | 16 |
| AH-3300 | 300 | 120 | Black | 200 | 88 | 120 | 75 | 16 | 16 |
| AH-3400 | 400 | 160 | Silver White | 200 | 88 | 120 | 75 | 16 | 16 |
| AH-3500 | 500 | 200 | Yellow | 200 | 88 | 120 | 75 | 16 | 16 |
| AH-3600 | 600 | 240 | Dark Blue | 200 | 88 | 120 | 75 | 16 | 16 |
| AH-3800 | 800 | 320 | Gray | 200 | 88 | 120 | 75 | 16 | 16 |
Hagoin(Hæ Gu′i: N) group was originally found in the year 1998, has been devoted to produce high quality rubber parts, plasticparts and metal parts for both domestic and oversea customers. Our products are widely used in automotive, industrial, Agriculture, aerospace, building, electronic, mobile phone, daily life etc fields. Our products get CE, RoHS, REACH, UL, LFGB certified, meet great demand on both USA and European markets. We have 46 employees, including 2 master′s degrees, 7 bachelordegrees and 37 experienced workers. We have flat vulcanized machines, injection machines, material mixer, punching machines, bending machines, laser, CNC center etc 35 sets. We have advanced test equipment, including the UV aging tester, tensile strength tester, tear strength tester, hardness reader, high and low temperature tester, ensure the quality meet customers′requirements.We also meet ISO9001 and TS16949 system. Most of our raw material are imported from USA, Germany, Japan, Thailand and Russia.
1. Are you factory or trading company? We are a factory with 20 years of experience in rubber and plastic industry. 2. What is your terms of packing? Generally, we pack our goods in neutral cartons or pallets or as your requirement. 3.How much is the sample fee? We can provide free sample if there is stock, but the express fee should be on customer's size 4. OEM/ODM is accept or not? OEM/ODM is welcomed, we can also print the logo according to your requirement. 5. Delivery Time Usually after the shipment, within 15days goods will be finished shipment. 6. Quality Control and After Sales Service During production we have strict inspection system for the production, if there is problem happens, we will try our best help solving the problem, such like bank, transportation, if there is quality problem confirmed, we also will undertake responsibility and suffer. Usually after the shipment, within 15days goods will be finished shipment.
