ISO9001 Acoustic Hanger LFGB ROHS Sound Isolation Ceiling Hangers

ISO9001 Acoustic Hanger LFGB ROHS Sound Isolation Ceiling Hangers

Brand Name: HAGOIN
MOQ: 1000
Price: $0.70-1.20
Payment Terms: T/T
Supply Ability: 1000 pieces per day
Detail Information
Place of Origin:
Shandong, China
Warranty:
More Than 5 Years
Feature:
Light Weight, High Strength, RESILIENT, Corrosion-resistant, Easy Installation, Fireproof Rustproof, Galvanized Steel
Installation:
Easy Installation
Surface Treatment:
Zinc Coated
Shape:
Customized
After-sale Service:
Online Technical Support
Material:
Rubber + Zinc Plated Steel, Flame Retardent Rubber+ Galvanized Steel
Project Solution Capability:
Graphic Design, 3D Model Design
Application:
Indoor Ceiling Decoration, Suspended Ceiling System, Hotel, Villa, Apartment, Office Building, Hospital, School, Mall, Sports Venues, Leisure Facilities, Supermarket, Home Office, Living Room, Bedroom, Dining, Babies And Kids, Outdoor, Storage And Closet,
Design Style:
Modern
Loading Capacity:
Free
Delivery Time:
With 15 Days
Certificate:
CE,ISO9001,LFGB, ROHS, CE
Feature 1:
Elastic And Long Life
Feature 2:
Stock
Feature 3:
ResilIent
Feature 4:
Reduce Vibration
Feature 5:
Higher Sound Transmission Class, STC
Feature 6:
Enhanced Low Frequency Attenuation
Packaging Details:
cartons and pallet
Highlight:

ISO9001 acoustic ceiling hangers

,

LFGB sound isolation hangers

,

ROHS compliant acoustic hangers

Product Description
Hagoin Stock Heavy Duty Extended Profile XP Rubber Sound Isolation Clip Eco-Friendly Modern High STC Low Frequency Attenuation

Acoustic Hangers and Soundproofing Clips for Part E Building Regulations Compliance

It is an acoustic sound isolation clip that is unique in its design with its dual density rubber polymers, each carefully designed and assembled to improve noise reduction over a broad range of frequencies while remaining stable

The extended profile helps to accommodate varying joist depths whilst , it is is installed up onto the required depths on the inside of the joist, creating an efficient and streamlined way to ensure a suited leveling of the ceiling instead of building a new framework or resulting to ad-hoc methods of installation.

Information
  • Dual density rubber acoustic sound isolation clip.
  • Extended profile design to accommodate varying room and joist heights.
  • Dramatically reduces airborne and impact noise as a high performing, slimline acoustic system.
  • Can be used on metal, wooden, brick and concrete structures.
  • Reduced points of contact to help de-couple ceiling systems.
  • Significantly improves sounds control in both high and low frequencies.
  • A significant improvement over standard resilient bars in both performance and fitting
  • Compliant with both Part E Building Regulations (England, Wales, Northern Ireland and the Republic of Ireland) and Building Standards Technical Handbook 2017 for Scotland for impact transmission.
Features
  • Soundproofing clips for building clip and channel independent frames.
  • For creating an acoustic dropped ceiling (Up to 65mm drop).
  • Ideal if you have uneven joists and need to create a level ceiling.
  • System reduces airborne sounds (e.g. music, tv & talking).
  • System reduces impact sounds (e.g. heavy footsteps, washing machines).
  • Compliant with both Part E Building Regulations (England, Wales, Northern Ireland and the Republic of Ireland).
  • Dimensions: 130mm x 76mm x 45mm
  • Noise reduction: 35 dB impact 60dB airborne*.
Product Description
ISO9001 Acoustic Hanger LFGB ROHS Sound Isolation Ceiling Hangers
ISO9001 Acoustic Hanger LFGB ROHS Sound Isolation Ceiling Hangers
ISO9001 Acoustic Hanger LFGB ROHS Sound Isolation Ceiling Hangers
ISO9001 Acoustic Hanger LFGB ROHS Sound Isolation Ceiling Hangers
ISO9001 Acoustic Hanger LFGB ROHS Sound Isolation Ceiling Hangers
ISO9001 Acoustic Hanger LFGB ROHS Sound Isolation Ceiling Hangers
ISO9001 Acoustic Hanger LFGB ROHS Sound Isolation Ceiling Hangers
Specification
Production Name Side Angel resilient sound isolation clip
Application Ceiling and drywall installation components
Feature 1 Quick and easy to install with standard drywall furring channel
Weight Capacity 60-80 lbs
Performance range STC 57 to STC 64
Packing & Delivery
ISO9001 Acoustic Hanger LFGB ROHS Sound Isolation Ceiling Hangers
ISO9001 Acoustic Hanger LFGB ROHS Sound Isolation Ceiling Hangers
ISO9001 Acoustic Hanger LFGB ROHS Sound Isolation Ceiling Hangers
ISO9001 Acoustic Hanger LFGB ROHS Sound Isolation Ceiling Hangers
ISO9001 Acoustic Hanger LFGB ROHS Sound Isolation Ceiling Hangers
ISO9001 Acoustic Hanger LFGB ROHS Sound Isolation Ceiling Hangers
ISO9001 Acoustic Hanger LFGB ROHS Sound Isolation Ceiling Hangers
ISO9001 Acoustic Hanger LFGB ROHS Sound Isolation Ceiling Hangers

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
